Concert Church Event Stage Rental LED Display,Indoor / Outdoor Use LED Screen,500mm×500mm / 500mm x 1000mm standard led rental screen in pixel p2.5 , p2.604 , p2.9 , p3.91 , p4.81 , p5.95 , p6.25……

Short Description:

Stage event being more and more popular, elements of stage contains lighting / audio / video……, LED display playing an important role in video, used for Live interaction, Video broadcast etc.
YWTLED as a professional led display manufacturer in led video wall more than 13 years, our stage event led display have many kinds of option for your indoor or outdoor event stage led video wall needs.
Yonwaytech,Your Trustworthy One-stop Stage Event Rental LED Screen Factory. Consulting For you.


Product Detail

500mm x 500mm standard cube led rental screen in pixel p2.5 , p2.604 , p2.9 , p3.91 , p4.81 , p5.95 , p6.25 for indoor or outdoor use.

500mm x 1000mm standard grid led rental screen in pixel p2.5 , p2.604 , p2.9 , p3.91 , p4.81 , p5.95 , p6.25 for indoor or outdoor use.

rental spec
480mm x 480mm in pixel p1.875 indoor, p2.5 indoor or outdoor, p5 indoor or outdoor.

512mm x 512mm in pixel p2 indoor, p4 indoor or outdoor, p8 indoor or outdoor.

576mm x 576mm in pixel p3 indoor or outdoor.

640mm x 640mm in pixel p2.5 indoor or outdoor, p5 indoor or outdoor, p10 indoor or outdoor.

768mm x 768mm in pixel p2 indoor, p4 indoor or outdoor, p8 indoor or outdoor.

960mm x 960mm in pixel p2.5 indoor or outdoor, p4 indoor or outdoor, p5 indoor or outdoor, p8 indoor or outdoor, p10 indoor or outdoor.

Upgrade your stage rental led display only changing the modules, same led cabinet can be compatible in different pixel.

For instance, if you have the p4.81mm first, and later want to have p3.91mm, no need to buy a complete panel,just to buy p3.91 led modules, and it could save around 40% cost for your business.

Yonwaytech,Your Trustworthy One-stop Stage Event Rental LED Screen Factory (3)

Ultra light weight, Easy operation.

YONWAYTECH 500mm×500mm event LED display cabinet is portable and good stability with weight of 6kg of indoor led display and 7.2kg of outdoor LED display, the cabinet thickness is only 80mm-85mm.

Yonwaytech,Your Trustworthy One-stop Stage Event Rental LED Screen Factory (4)

Humanization design, Quick Assembly.
Fast locks and locate pins, panel lifting handle, removable power and receiving box,hidden test button, stack installation joggle, power and signal indicator, power connector, signal connector, all led rental display details just to make it more easier and faster in installation within 20 seconds.

Yonwaytech,Your Trustworthy One-stop Stage Event Rental LED Screen Factory (1)

Die-cast aluminum cabinet design light and easy to transport, good flatness and seamless.

A strong and reliable cabinet structure not only important during event show safe, but also good for your business ROI .

Light weight led panels make the LED display is good for transport and installation, saving time and a good amount of money on your labor cost.

Yonwaytech,Your Trustworthy One-stop Stage Event Rental LED Screen Factory (6)

High Refresh Rate, High Contrast, High Grey Scale, Bright Color.

Refresh rate of YONWAYTECH stage event rental LED screen can be achieved in 3,840hz fully matching the demand of live feed switching, even under 1/2000 shutter professional camera shooting.

Yonwaytech,Your Trustworthy One-stop Stage Event Rental LED Screen Factory (7)

Universal led panels also can be combination installed for led video wall.

Not only good for stage rental temporary use,but also available in digital led billboard fixed installation.

IP65 outdoor water proof makes more reliable.

Yonwaytech,Your Trustworthy One-stop Stage Event Rental LED Screen Factory (8)

 Ultra-wide viewing angle give you the largest screen viewing area.

Viewing angle up to 140° in vertical and horizontal.

Audiences seeing from any angles, the stage rental led display would still being a natural and vivid image.

Yonwaytech,Your Trustworthy One-stop Stage Event Rental LED Screen Factory (5)

Technical Parameter: Y-IR-Stage Event -V01 Indoor Series

Indoor

P2.64

P2.98

P3.91

P4.81

Pixel Pitch(mm) 2.64mm 2.976mm 3.91mm 4.81mm
Pixel density(pixels/sq.m.) 147456 112896 65536 43264
Module size 250mmx250mm 250mmx250mm 250mmx250mm 250mmx250mm
Panel resolution(dots) 192×192 / 192×384 168×168 / 168×336 128×128 / 128×256 104×104 / 104×208
Panel size 500mmx500mm / 500x1000mm
Driver IC MBI5124 (ICN 2153 Optional)
Color Grayscale(Bit) 14-16bit
Pixel Configuration SMD1515 SMD2121 /SMD1921 SMD1921/SMD2121 SMD2121 /SMD1921
Viewing Angle(°) 140°/ 140°
Brightness(nit) ≥1000CD/m² ≥1000CD/m² ≥1200CD/m² ≥1200CD/m²
Driving Type 1/32 1/28 1/16 1/13
Transmission Distance(m) CAT-5E≦130m,Multi-mode Optical Fiber≦500m,Single Mode Optical Fiber≦10km
AC Input Frequency(Hz) 50
Gray Scale per Color(level) 8192
IP Rate (Front/Rear) IP43
Maximum Power Consumption(W/m²)Average Power Consumption(W/m²) ≦700W/m²
  ≦250W/m²
Lifetime Typical Value(hrs) 100000
Refresh Rate (Hz) ≥3840Hz
AC Input Voltage(V) AC: 110V|220V±10%
Cabinet installation type Fixed/Rental



Y-OR-Stage Event -V01 Outdoor Series

Outdoor

P2.976

P3.91

P4.81

P5.95

Pixel Pitch(mm) 2.976mm 3.91mm 4.81mm 5.95mm
Pixel density(pixels/sq.m.) 112896 65536 43264 28224
Module size 250mmx250mm 250mmx250mm 250mmx250mm 250mmx250mm
Panel resolution(dots) 168×168 / 168×336 128×128 / 128×256  104×104 /104×208 84×84 / 84×168
Panel size 500mmx500mm / 500x1000mm
Driver IC MBI5124 (ICN 2153 Optional)
Color Grayscale(Bit) 14-16bit
Pixel Configuration          SMD1415 SMD1921/SMD2727 SMD1921/SMD2727 SMD2727 /SMD3535
Viewing Angle(°) 140°/ 140°
Brightness(nit) 4500CD/m² 4500CD/m² 4500CD/m² 5000CD/m2
Driving Type 1/10 1/10 1/13 1/7
Transmission Distance(m) CAT-5E≦130m,Multi-mode Optical Fiber≦500m,Single Mode Optical Fiber≦10km
AC Input Frequency (Hz) 50&60
Gray Scale per Color(level) 8192
IP Rate (Front/Rear) IP65
Maximum Power Consumption(W/m²) Average Power Consumption(W/m²) ≦900W/m²
≦300W/m²
Lifetime Typical Value(hrs 100000
Refresh Rate(Hz) ≥3840Hz
AC Input Voltage(V) AC: 110V|220V±10%
Cabinet installation type Fixed/Rental
