GOB P1.2 P1.5 P1.8 Flexible LED Display Soft P2 P2.5 LED Screen
GOB P1.2 / P1.5 / P1.8 Flexible LED Display
High-Protection Fine-Pitch Flexible LED Display
Yonwaytech GOB P1.2, P1.5 and P1.8 Flexible LED Displays combine high-resolution imaging, flexible design, advanced GOB encapsulation and high refresh rate for vivid, smooth and reliable video wall performance.
Ideal for curved walls, cylindrical displays, retail spaces, exhibitions, stage backdrops and creative architectural installations, these displays provide excellent design flexibility with enhanced LED surface protection.
Advanced GOB Protection
GOB (Glue-on-Board) technology encapsulates the LED surface with a transparent protective layer, providing additional protection for LED chips, soldering areas and the PCB.
- ✔Impact Resistance: Helps protect LED components against accidental impact.
- ✔Scratch Resistance: Reduces surface damage during handling and installation.
- ✔Dust Protection: Helps reduce dust accumulation around LED components.
- ✔Easy Cleaning: Provides a smoother surface for convenient cleaning and maintenance.
- ✔Enhanced Durability: Provides additional protection for densely arranged fine-pitch LEDs during transportation, installation and daily operation.
GOB protection makes flexible LED displays more resistant to everyday handling while maintaining their flexibility and visual performance.
Note: GOB enhances LED surface protection but does not automatically make the entire display waterproof or suitable for outdoor use.
Flexible Design for Creative Applications
The flexible soft PCB allows the LED display to follow convex, concave, cylindrical and wave-shaped structures, creating smooth curved surfaces for distinctive visual installations.
Available pixel pitches include:
Professional Engineering & Precision Curved Design
A successful curved LED project requires more than flexible modules. Yonwaytech provides professional pre-sales project consultation, engineering drawings and customized mechanical design to turn creative concepts into practical LED solutions.
Our engineering services include:
- Screen layout and pixel resolution planning
- Professional project drawings
- Precision curved cabinet and cylindrical structure design
- Supporting frame and installation planning
- Power, signal and maintenance layout
From precise curvature to seamless cabinet alignment, we focus on structural accuracy, practical installation and long-term reliability.
Easy Assembly, Front Maintenance & Ultra-Slim Design
Yonwaytech Flexible LED Display is designed for easy assembly, convenient front maintenance and maximum installation flexibility.
Individual LED modules can be removed and replaced directly from the front, without requiring rear access — ideal for wall-mounted, curved, column and space-limited installations.
For customized projects, Yonwaytech can tailor the screen thickness, module layout, supporting structure and curvature according to the available space and installation requirements, making the display more compact and precisely integrated into your project.
Why Choose Yonwaytech?
Technical Parameter:
Y-IF-Soft Ribbon-V02
|
Pixel pitch(mm) |
1.2 |
1.5 |
1.8 |
2 |
2.5 |
|
LED Type |
SMD1010 |
SMD1212 |
SMD1515 |
||
|
Module Size(W x H)mm |
320×160 |
||||
|
Module resolution(W x H) |
256×126 |
208×104 |
172×86 |
160×80 |
128 x 64 |
|
Module pixels(dots) |
32768 |
21632 |
14792 |
12800 |
8192 |
|
Diver Mode(Scan) |
1/64 |
1/52 |
1/43 |
1/40 |
1/32 |
|
Brightness(cd/m2) |
≧500 |
≧700 |
|||
|
Grey Scale(bits) |
≧14 |
||||
|
Color Temperature(K) |
8000～10000 Optional |
||||
|
Refresh Rate(Hz) |
≧3840 |
||||
|
Module Signal |
HUB320 |
HUB75e |
|||
|
Module Shell Material |
Silicone |
||||
|
Max Power Consumption(W/m2) |
≦600 |
≦550 |
≦500 |
≦480 |
≦450 |
|
Average Power Consumption(W/m2) |
≦180 |
≦160 |
≦150 |
≦150 |
≦150 |
|
View Angle(H°/V°) |
≧160° / ≧140° |
||||
|
Bending Radian |
≥165° |
≥162° |
≥150° |
≥145° |
≥135° |
|
Mini View Distance(m) |
≧1 |
≧1.5 |
≧2 |
||
|
Cabinet Material |
Aluminum / Iron Customizable |
||||
|
Operating TEMP. (℃) |
-20℃~60℃ |
||||
|
Storage TEMP. (℃) |
-10℃~40℃ |
||||
|
Operation Humidity (Rh) |
25%～85%(Working) ,10%～90%(Storage) |
||||
|
Input Voltage(V) |
100V～240V Optional |
||||
|
Input Power Frequency(Hz) |
50Hz~60Hz |
||||
|
Failure Rate |
＜1/ 50,000 |
||||
|
Signal Input Format |
SDI, RGBHV,YUV,YC,Composite,HDMI,DVI,SD/HD-SDI etc. |
||||
|
Life Time(Hrs) |
≧100,000.00 |
||||
|
Service Access |
Front / Back Optional |
||||
|
IP Level(Front/Rear) |
IP31 Indoor |
||||
Turn Your Ideas into Reality
From the first concept to the finished display, Yonwaytech helps make your LED project easier to design, manufacture, install and maintain.
Yonwaytech — Your One-Stop LED Display Manufacturer & Project Consultant
-
